Hierarchy Board is empty after loading Sigma Studio 4.5.

Hello,

I created a complex Reverb algorithm with the ADAU 1452 and tried to export the hierarchy board of it to use it for other Projects (ADAU 1462).

I selected all items (STRG + A) and created a Hiereachy Board via "Create Board":

After this I saved the board:

and tried to load it again in the same project (for ADAU 1452) and also in another project (for ADAU 1462):

The result is an empty board in both projects.

If I copie the board via STRG + C I can insert the board in the same project (for ADAU 1452) but not in another project (for ADAU 1452) (all Projects are done in Version 4.5)

I hope you can hepl me out.

Many thanks in advance!
