Is there any image module that changes with time
I plan to use the MFxLMS module in ADAU1452 and Sigma4.7 for noise control. There are two Mean Square Error outputs (two red dots on the right of the module) as shown in the figure below. After training, I need to record the change curve of these two outputs with time from the beginning to judge whether the control is successful. Is there such a module?
Edit Notes
1
[edited by: javaboy at 12:11 PM (GMT -5) on 7 Mar 2023]
Audio Signal Processors
adau1452
software
SigmaDSP Audio Processors
sigmastudio4.7
Hello javaboy,
I guess what you ask for is like a graphical view of the signal at the output of the block that changes in real time and you want to observe and measure it like any graph? I don't think you can do that. I already mentioned in another post of yours that there is a real time display block which shows a real time graphical view of the signal level vs time. But that won't be effective. It can only be used for small debugging applications.
Regards,
Harish
Thank you very much.
