sigmastudio tool often error

HI walkercc:

Any chance you can provide your schematic or a sequence for reproducing this error?

Thank youi

Miguel

At least open more than two schematic, and keep sure the schematic have more module , and do some like copy and paste operation at a schematic. and switch another schematic window. it's must show this error.

I have a another question. How module INIT_modulename will be called.

I think it will be called at Adi_ss_init, but it's not. If use stateC memory.

what's time the memory will be inited?

It's like init stateC memory(offchip DDR) at first BPROCESS_XXXX function call ?

What version of SigmaStudio are you running?

There is a known bug related to memory allocation with copy and paste, but I believe they are resolved in the latest release. Please upgrade if that is an option.

If you cannot for some reason, are you using Control-C and Control-V? Try selecting the object to be copied, and click-drag while holding down the control key. This is known to be more stable in earlier releases with this bug.

Copy and paste across projects has been a bigger problem in some past releases. If you need to do this, try right-clicking on the object and selecting "copy" from the context menu. then right clicking in an empty area and selecting "paste." This may be more stable than the shortcut keys. If the paste is successful, save the project, close it, and reopen it so SigmaStudio can allocate memory for all of the blocks correctly.

Again, the best workaround by far is to upgrade to the latest release if that is possible for you.

Ken

ok. I will follow your advice.

My sigmastudio version is 3.15 build3 release.
