Aardvark programming SigmaDSP without EVAL-ADUSB2EBZ

Burned my programmer EVAL-ADUSB2EBZ, I found the solution to generate the file. HEX for programming with Aadvark or other EEprom programmer.

1- Loading file .dspproj (schematic)

2- In Hardware configuration:

Selection: USBi programmer

I2C 0x68 (104) - ADAU1701 (example)

I2C 0xA0 (160) - E2prom

3- Click in Link Compile Download

A USB communication failure has occured. (no problem).

4- In Hardware configuration:

Selection ADAU1701 right mouse click option (Write Lastest Compilation to E2prom)

Generator \IC2 folder in project com E2prom.HEX file.

5- Enter in config - IC2 WinE2PromLoader

Click download file to E2prom

Browser - \IC2 folder with E2prom.HEX file

Click Display file:

Click in all text and control+C for copy:

Instalation WinHEX text editor

http://winhex.en.softonic.com/

Selection FILE + NEW 16Kb:

In offset position 00000000 + press control+V

Click OK

Selection ASCII HEX format

Figure final:

File save name.txt in folder

OPen Flash Center TotalPhase Aardvark software

Configure your E2prom

Click in load file

Select : name.txt in Load file

Check hex positions values e write

Done!!!!!!!!!!!!!!!!!!!!!!!
